TY180 Hydraulic Puller Machine Max continous pulling force:150KN

FOB Reference Price:Get Latest Price
US $90,000-100,000 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland), Jiangsu, China (Mainland)
Brand Name:
BOYU BRAND
Model Number:
TY180-106
Condition:
New
After-sales Service Provided:
Engineers available to service machinery overseas
Packaging & Delivery
Packaging Details
According to the customer request
Port
Shanghai
Lead Time :
30 days

1. Max pull: 180kN
2. Engine: Cummins 239kw
3. Main Parts from: German Rexroth
4. German WIKA

TY180 Hydraulic Puller Machine Max continous pulling force:150KN



The machine allows for the tension stringing of 4-bundle conductor of 630mm2

and below in mountainous and hilly areas, and of 4-bundle conductor of 720mm2

and below in flat lands; besides,

it can be used for traction stringing of OPGW or ADSS optical cable and 500kV traction stringing in various terrains.



Performance parameter

Max intermittent pulling force :180KN

Max continous pulling force:150KN

Corresponding speed:2.5km/h

Max continous pulling speed:5km/h

Corresponding pulling force:75KN

Structure parameter

Puller wheel diameter:700mm

Groove number:10

Max diameter of applicable steel wire rope :27mm

Electric systerm:24V

Max diameter of applicable wire coil:1400mm

Total weight:6800kg

overall dimension:4300×2360×2380mm

Main comfigurations

Engine:Cummins

hydraulic pump:German Rexroth

Main moter:German Rexroth

speed reducer :German Rexroth

Hydraulic meter: German WIKA



Performance parameter

 Max intermittent pulling force 180KN
  Max continous pulling force 150KN
  Corresponding speed 2.5km/h

Structure parameter

 Puller wheel diameter 700mm
  Groove number 10
  Max diameter of applicable steel wire rope 27mm

Main comfigurations

 Engine Cummins
  Hydraulic pump

 German

Rexroth

  Hydraulic meter German WIKA



More pictures:

Production workshop

Company introduction

Jiangsu Province Yixing Boyu Electric Power Industry Company is located in west side of the beautiful and fertile Taihu Lake.

Our company is high-tech enterprise of Jiangsu province having six patents, including two invention patents. Our company has a total area of 42800 square meters, having formed four series products:

1: Electric power construction tools

2: Nonmetallic galvanized the production equipment (Achieved high-tech products)

3: Numerical control machine

4: Low voltage no power-arc furnace compensation system

History

Founded in 1993, Yixing city power machinery factory

Established in 1997, Yixing city Boyu power machinery Co., LTD

In 2001 the company passed ISO9001 certification, and obtain the AAA certificate

In 2006 attains the Wuxi city contract trustworthiness enterprise, also achieved famous brand product in Wuxi city

In 2007 attains the high-tech enterprise of Jiangsu province, also achieved brand-name products in Jiangsu province

In 2009 reworded significant achievement in Wuxi city

In 2010 Boyu cooperated with Germany famous Caesar Company establishing the Boset brand

In 2010 achieved the national ministry of science and technology innovation in science and technology project.

To November 8, 2010, Boyu enterprise has already sell puller and tension equipment (excluding mobile ground grinding) nearly 4000 sets. Our products are sold well in Sudan, Kenya, Angola, Pakistan, Burma, India, Mexico,Germany.







....
